Pellet stove Extraflame Annabella 2.4-8.0kW

The Extraflame Annabella pellet stove with its painted steel cladding impresses with its clever, flat shape. In simple white, attractive burgundy or subtle black, it fits into every home.

The large pane ensures a fantastic view of the fire. The Annabella pellet stove is ingeniously designed so that the viewing window hardly loses any soot (glass clean control).

The option to heat a second room using a warm air duct (pipe) is quite clever .

Perfectly coordinated air supply and patented smoke extraction create highly efficient combustion

Primary and secondary air are perfectly coordinated for thorough combustion and an efficiency of over 90%. An electronic control unit (Electronic Air Control) is integrated into the Annabella pellet stove, which ensures effective operation. Nothing needs to be readjusted manually.

The remarkable, patented smoke extraction ensures optimal chimney draft.

Automatic control depending on the set room temperature

The integrated warm air fan ensures that the room warms up really quickly. The regulation is fully automatic (room temperature control).

Once the desired room temperature is reached, the Annabella pellet stove switches to an economical power level.

The system detects a power failure and intelligently restarts the pellet stove (auto-restart).

Cast iron ensures safety and durability

The pull-out fire chamber and the combustion chamber doors are made of magnificent cast iron. Kiln casting is traditionally the first choice in kiln construction.

Thanks to its pressure resistance, cast iron in the Annabella pellet stove is wear-resistant and extremely durable. Ideal for the firebox, oven door and built-in parts.

Low fuel consumption thanks to optimal coordination of all components

Your Annabella pellet stove only uses 0.6 kg to 1.8 kg of wood pellets per hour. Use the Annabella pellet stove as an efficient main heater or as a precise additional heater.

Quick and easy cleaning

Thanks to the ash pan, cleaning the Annabella pellet stove is easy.

Advantages at a glance:

• Dimensions (W x D x H): 703 x 320 x 1078 mm
• Heat output: 2.4 - 8.0 kW
• Type: Air led
• BImSchV level 2 fulfilled
• Efficiency: >90%
• Hourly consumption: 0.6 - 1.8 kg/h
• Tank capacity: approx. 14 kg
• Weight: 136kg
• Remote control: Yes
• Exhaust pipe diameter: 80 mm
• Number of possible channelizations: 1
• Connection options for the smoke pipe: top, rear, right side
• Connection options for sewer pipe: top, rear, right side
• Diameter of supply air pipe: 50 mm
• Diameter of sewer pipe: 80 mm
• Connection: 230 V
• Maximum heating volume: 230 m3
• Removable brazier: Yes
• Pull-out ash pan: Yes
• Maximum length of channeling. 6 m
• Ducting by additional thermostat: Yes
• Deactivation of the ducting possible: Yes, can be switched off - heat emission either into the room or into the duct
• Manual cleaning of heat exchanger possible: Yes

Integrated high-quality technologies at a glance:

• Auto Re-Start (ARS) - Automatic restart after power failure
• Clean Glass Control (CGC) - window rinsing - soot deposits are avoided
• Electronic Air Control (EAC) - Electronic, coordinated control of primary and secondary air ensures efficiency
• Resistant Door at time (RDT) - Low-wear, stable door made of cast iron
• Room Temperature Control (RTC) - monitoring the room temperature ensures optimal feel-good operation
• Hard Reset Program (HRP) - possibility of resetting to factory settings
• Pellet Level Control (PLC) - Economical - Monitoring the amount of pellets
• Auto Clean Checkup (ACC) - Automatic cleaning of the brazier after the set operating hours have been reached
• Delay Stop System (DSS) - Possibility of switching off the pellet stove with a time delay
• Chrono Thermostat Program (CTP) - weekly programming with settings for 4 time periods per weekday
• Keylock Systen (KLS) - Setting a key lock (child lock) on the display to prevent unauthorized operation
• Interface Control Temperature (ICT) - oven control possible depending on external thermostat
• Rate Adjustment Program (RAP) - Setting the direction of airflow

Impressive installation by trained specialist staff

Take advantage of the opportunity and have your pellet stove installed by a trained specialist company. This not only gives you peace of mind, but also secures you the full manufacturer's warranty.
